Impinj R220 RFID Reader

(1 customer review)

$1,450.00 + Tax

Ask for More Info

Adapter not included.

Available on backorder

SKU: IPJ-REV-R220-EU12M1 Categories: , ,
Description

Impinj R220 RFID Reader

For optimum visibility of tagged inventory and assets, the Speedway Revolution R220 RFID Reader provides the performance, quality, and dependability required. These readers automatically adapt for optimum functionality and are able to maintain high read rates regardless of RF noise or interference. Impinj’s innovative Speedway® Revolution RFID Reader with Autopilot functionality optimizes its operation according to the environment automatically, providing the highest performance at all times.

Speedway Revolution reader builds on the history of the original, EPC-certified Speedway reader, which was the first high-performance reader to support the EPCglobal UHF Gen 2 standard in its entirety (rather than just being upgraded).

The Speedway R220 reader is backed by a set of software, hardware, and antennas that provide application and deployment flexibility, making setup and extension easier than before.

Impinj R220 RFID Reader

With its superior quality design, it provides the high efficiency, value, and effective use you are looking for.



If you need assistance selecting the appropriate RFID Reader for your needs, please contact us.

Data Sheet — Impinj R220 RFID Reader

Quick Start Guide — Impinj R220 RFID Reader

Additional information
MANUFACTURER

AIR INTERFACE PROTOCOL

GS1/EPCglobal UHF Class 1 Gen 2 (ISO 18000-6C)

OPERATING FREQUENCY

EU1: 865-868 MHz

TRANSMIT POWER

(PoE): +10.0 to +31.5 dBm (EU1 limited to +30 dBm)' (External DC Power):+10.0 to +32.5 dBm (Listed/Certified power supply) (EU1 limited to +31.5 dBm, JP2 limited to 30 dBm)

MAX RECEIVE SENSITIVITY

-84 dBm

MAX READ RATE

Up to 200 tag reads per second

DATA INTERFACE

RS-232, ethernet

GPIO

4 GPI optically isolated 3-30V/ 4 GPO optically isolated, 0-30V, non-isolated 5V, 100mA supply (DB-15)

POWER SOURCES

AC-DC power supply: all models IEEE 802.3af PoE: all models

ANTENNA PORT

2 RP-TNC female ports (connects to RP-TNC male), monostatic

DIMENSIONS

190.5 x 175.3 x 30.5 mm (7.5 x 6.9 x 1.2 in)

WEIGHT

0.7 kg (1.5 lbs)

IP RATING

IP 52

OPERATING TEMPERATURE

-20 ºC to +50 ºC (-4 ºF to +122 ºF)

HOST API

Java, .NET

DEMO SOFTWARE

Impinj ItemTest Software
